3XP



Model 3XP is designed to be used with our full range of tactical optics; the EG1, FC1, RV1 and RV2. Precise adjustment of elevation and azimuth centers the red dot in your field of view. The 3XP magnifier significantly improves accuracy on medium and long range targets. Its machined aluminum-alloy housing, multi-layer coated lenses, and superior waterproofing make the 3XP exceptionally ruggedized. Mounts with the provided ring mount or with an optional ARMS #78 T.I.T.S. TM

MSRP: $297

Unique Features

  • 6061-T6 Aircraft Quality aluminum body / matte black hard anodized
  • 2.5” Eye Relief
  • 22 mm Objective Lens
  • Wide range of click movements (100 Clicks)
  • Dimensions : 110 mm x 50 x 70 mm (L x W x H)
  • Weight w/o Mount : 336 g (11.8 Oz)
  • Compatible with ARMS #78 T.I.T.S. TM
  • Submersible to 30 Ft depth

Technical Specifications

MODEL 3XP
Objective Lens 22 mm
Eye Piece Lens 25 mm
EYE RELIEF 2.5”
WEIGHT 251 g (11.8 Oz)
OVERALL DIMENSIONS 110 x 44 x 45 mm (L X W X H)
FOV 63 feet at 100 yards
STORAGE TEMP RANGE -41° ~ 71° C, (-42° ~ 160° F)
OPERATING TEMP RANGE -32° ~ 71° C, (-25.6° ~ 160° F)
MIL SPEC CONFORMITY MIL-STD 810G Environment Testing
MOUNT Ring Mount / ARMS #78 T.I.T.S.

* RANGE MAY VARY DEPENDING ON THE LIGHT CONDITIONS
